Elcometer 7410 Concrete Moisture Meter Main Image

Elcometer 7410 Concrete Moisture Meter

A simple non-invasive moisture meter to enable the level of moisture in a concrete, gypsum or other floor screeds, to be detected quickly without the need to penetrate the substrate surface. The Elcometer 7410 has built in transmitter and receiver electrodes which emit a low level AC electrical field within the structure and then measuring the electrical impedance, which varies dependent on moisture content. A simple moving coil display will give instant readings

The Elcometer 7410 is designed for the concrete flooring industry to quickly establish the level of moisture within the structure prior to any coatings or floor coverings are installed on the concrete base. Penetrating the surface to get an accurate moisture level within the structure is important as surface evaporation may show the moisture level as low, but within the structure there is likely to be residual moisture until the complete substrate has dried out. The Elcometer 7410 uses a non-destructive (NDT) method of measuring the moisture content below the surface and therefore providing a more accurate indication of how dry the structure is prior to further work being carried out, such as floor coverings added or coatings painted on to protect the concrete, gypsum or screeded base layer. By creating a small low frequency AC field between electrodes on the reverse of the Elcometer 7410, the impedance can be measured to a depth of about 20mm below the surface. The impedance will vary depending on the amount of moisture, and the moisture level can be read on the moving coil needle display on the front of the 7410

ESS Code: SPMR.23

  • Non-invasive form of moisture content detection in concrete
  • Fast response time with readings almost instantaneously displayed
  • Portable hand held device
  • Easy to read moving coil needle display
  • Detects moisture content to a depth of 20mm
  • Simple push button operation
  • Moisture content from 0% to 6% is displayed
  • Comparative readings for gypsum and other floor screeds are shown on a 0-10% scale


Moisture Content Range, concrete: 0 – 6%
Moisture Content Range, floor screed: 0 – 10%
Penetration depth: Up to 20mm
Substrate type: Concrete, gypsum floor screed
Power: LR6 AA Batteries x 2
Dimensions: 160 x 85 x 38 mm
Weight: 344 gms


Technical Document

Elcometer 7410 Concrete Moisture Meter Data Sheet

Elcometer 7410 Concrete Moisture Meter Data Sheet
Technical Document

Elcometer 7410 Concrete Moisture Meter Quick Start Guide

Elcometer 7410 Concrete Moisture Meter Quick Start Guide
Technical Document

Elcometer 7410 Concrete Moisture Meter Instruction Manual

Elcometer 7410 Concrete Moisture Meter Instruction Manual
  • Soft carry case
  • Calibration Certificate
  • Instruction manual
