Spectra GL622IR Dual Grade Laser

The Spectra GL622IR is a rugged, automatic self-leveling laser with a class 1 invisible infrared beam and a grade capability from -25% to + 25%.

The radio remote control that comes with the GL622IR allows for the full capabilities of the laser to be operated from up to 150m away. With its graphic interface and simple menus, the GL622IR is simple to operate and easy to use for everyone on site.

ESS Code: SDGL.26

Key Features of the Spectra GL622IR Dual Grade Laser

-  800m diameter range

-  Automatic self-leveling

-  Anti-vibration filter for increased stability in adverse weather conditions

-  Invisible class 1 infrared beam (class 1 is the safest beam classification possible)

-  Automatic grade matching

-  Grade range from -25% to +25% to reduce errors and improving productivity

-  Temperature compensation through automatic internal temperature checks and calibration to ensure the laser is operating at the maximum efficiency in any temperature

-  Automatic axis alignment

-  Virtual masking function

- Technical Specifications of the Spectra GL622IR Dual Grade Laser

- Leveling accuracy1,3: ± 0.5 mm/10 m,

- 1/16“ @ 100 ft, 10 arc seconds

- Grade accuracy1,3: ± 1.0 mm/10 m,

- 1/8“ @ 100 ft, 20 arc seconds

- Grade temperature drift sensitivity:

- ± 0,3 mm / 10 m / 1°C; 1/16” @ 310 ft. @ 1°F

- Operating diameter1,2: appr. 800 m (2600 feet)

with detector

- Grade range (Y, X-GL622N/GL622IR):

- ± 25% both axes (not simultaneously)

- Rotation: 300, 600, 750 rpm

- Laser type: 639 nm (GL622IR: typ.830 nm)

- Laser class : Class 2 (GL622IR: class 1)

- Self-leveling range: appr. ± 14°

- Leveling indicators: LCD indications and LED flashes

- Radio range (HL760)1,2,4: up to 150 m (490 ft)

- Power source: NiMH battery pack

- Battery life: 35 hours NiMH

- (GL622IR: 40 hours NiMH)

- Operating temp.: -20°C to 50°C (-4°F to 122°F)

- Storage temp.: -20°C to 70°C (-4°F to 158°F)

- Tripod attachments:

- 5/8 x 11 horizontally and vertically

- Dust and waterproof: Yes - IP67

- Spectra GL622IR

- HL760 Laser Reciever

- RC602N Remote Control

- C70 Clamp

- Charger

- Battery Pack

- Carry Case

- Standard Staff

- Wooden Tripod
