Fluke 7103 Micro Bath Temperature Calibrator

The Fluke 7103 Wet well Temperature Calibrator is the ideal instrument for calibrating temperature probes of a non-standard diameter. With a silicon based heating and cooling medium, 48mm working area and wide temperature range of -30 to 125oC many different sized probes can be accommodated.

Fluke range of fluid baths for non-standard temperature probe calibration. The Fluke 7103 is a light weight, portable fluid bath temperature calibrator for use with probes that are not the usual 3mm or 6mm standard, of which there are many. Mercury in steel or bimetallic temperature probes tend to be of a larger diameter and therefore unsuitable for calibration in a Dry Block Calibrator.

The Fluke 7103 Fluid wet well calibrator can accommodate probes with a diameter of up to 48mm and a depth of 140mm. With a range of -30 to 125oC it can cover applications where temperature is either side of 0OC. Applications in the food and drinks sector, or pharmaceutical industries as typical examples. With its light weight, small size and splash proof lid, the Fluke 7103 can be easily managed by one person.

ESS Code: HDBC.12

  • Fluid bath, not Dry Block
  • Wet well size of 64 mm dia. x 140 mm deep (2.5 x 5.5 in) (working area is 48 mm [1.9 in] in diameter)
  • Temperature range of -30°C to 125°C (–22°F to 257°F)
  • Size of only 23 x 34 x 26 cm (9 x 13.2 x 10.5 in)
  • Portable and easy to carry at 9.8 kg (22 lb) with fluid
  • Accuracy of ±0.25°C

Range: -30°C to 125°C (–22°F to 257°F)
Accuracy: ±0.25°C
Well Volume: 1.0 Litre
Fluid medium: Silicon Oil
Dimensions:230 x 340 x 260 mm
Weight: 9.8 Kgs (including fluid)
Power Supply: 94–234 V AC (±10%), 50/60 Hz

Technical Document

Fluke 7103 User Manual

Fluke 7103 User Manual
Technical Document

Fluke 7103 Data Sheet

Fluke 7103 Data Sheet
Technical Document

Fluke 7103 Safety Sheet

Fluke 7103 Safety Sheet

•    Calibrator
•    Silicon fluid
•    Probe basket
•    No spill lid
•    Stir bar
•    Black test lead set
•    User manual
•    Mains lead
•    Carry case

Lead time: 1 days

Delivery and Collection charges will be displayed in the basket at checkout stage and will vary depending upon your location and transport method applied.

Set up an Account

Login or create an account to gain access to your account history and document library. Link your Web Account to your ESS Credit account to hire online, contact us for details.

Fluke 7103 Micro Bath Temperature Calibrator

hire Price

ESS Code: HDBC.12
£220.00 Weekly

Rates exclude VAT and Damage Waiver

£220.00 Ex. VAT


Minimum hire period: 5 days

Lead time: 1 day

Please note you will be charged for the minimum hire period if your order is for a period less than this. A web account linked to your ESS Credit account is required to hire online.

Key Product Features

  • Temperature range of -30°C to 125°C (–22°F to 257°F)

  • Wet well for probe immersion. Almost any size probe can be calibrated

  • Well size 64 mm dia. x 140 mm deep (2.5 x 5.5 in) (working area is 48 mm [1.9 in] in diameter)

  • Media fluid included with the Calibrator
